Nền tảng
- Đặc điểm CPU
-
- LGA1151 Socket
- Thế hệ 8, Intel Core/Pentium/Celeron
- Chipset
- Intel Z370
- Hãng sản xuất CPU
- intel
- Card đồ hoạ
-
- Hỗ trợ công nghệ đồ hoạ AMD CrossFire 3 chiều
- Hỗ trợ công nghệ đồ hoạ NVIDIA SLI 2 chiều
Lưu trữ
- Bộ nhớ trong
-
- 6 x cổng SATA 6 Gb/s, hỗ trợ Raid 0, 1, 5, 10
- 3 x cổng M.2 slots, hỗ trợ Raid 0, 1
PCIe 3.0 x 4 NVMe U.2 SSD
PCIe 3.0 x 4 and SATA 6Gb/s
M2_1, M2_3 slots (hỗ trợ 2242/2260/2280/ 22110 storage devices)
M2_2 slot (hỗ trợ 2242/ 2260/2280 storage devices)
Intel Optane Memory Ready M.2
- RAM
-
- 4 x DDR4 , hỗ trợ tối đa 64 GB
- Hỗ trợ 4000+ (OC)/3866 (OC)/3733 (OC)/3600 (OC)/3466 (OC)/3400 (OC)/3333 (OC)/3300 (OC)/3200 (OC)/3000 ( OC)/2800 (OC)/2667/2400/2133 MHz
- Kiến trúc bộ nhớ kênh đôi
- Hỗ trợ non-ECC, un-buffered
- Hỗ trợ Intel Extreme Memory Profile (XMP)
Âm thanh
- Đặc điểm âm thanh
-
- Realtek ALC1220 Codec
- 7.1-Channel High Definition Audio
Kết nối
- LAN
- 1 x KillerTM E2500 Gigabit LAN controller
- Kết nối I/O bên trong
-
- 3 x PCIe 3.0 x16
- 3 x PCIe 3.0 x1
- 1 x 24-pin ATX main power connector
- 1 x 8-pin ATX 12V power connector
- 6 x SATA 6 Gb/s connectors
- 2 x M.2 slots
- 2 x USB 3.1 Gen1 connectors (supports additional 4 USB 3.1 Gen1 ports)
- 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports)
- 1 x 4-pin CPU fan connector
- 1 x 4-pin water pump fan connector
- 4 x 4-pin system fan connectors
- 1 x Front panel audio connector
- 2 x Front panel connectors
- 1 x RGB LED connector
- 1 x TPM module connector
- 1 x Chassis Intrusion connector
- 1 x Clear CMOS jumper
- 1 x BIOS FLASHBACK+ button
- 1 x 2-Digit Debug Code LED
- 1 x LED power input connector
- HDMI
- x 1 (hỗ trợ độ phân giải tối đa 4096 x 2160@30 Hz, 2560 x 1600@60 Hz)
- USB
-
- ASMedia ASM3142: 2 x 3.1 Gen2
- ASMedia ASM1074: 4 x 3.1
- Intel Z370 Chipset:
6 x 3.1 Gen1
7 x 2.0
- Kết nối khác
-
- DisplayPort
- Optical S/PDIF-Out
- Clear CMOS Button
Thông tin chung
- Nhà sản xuất
- MSI
- Kích thước
-
- Dạng thiết kế ATX
- 30,5 x 24,4 cm
- Loại máy
- Bo mạch chủ
