Nền tảng
- Đặc điểm CPU
-
- Intel Atom E3940.
- Single Socket FCBGA1296, CPU TDP 9.5 W
- Card đồ hoạ
-
- Intel HD Graphics
- Dual channel 48-bit LVDS(max. resolution up to 1920x1200@60Hz), HDMI(max. resolution up to 3840x2160@30Hz)
Lưu trữ
- RAM
- Hỗ trợ tối đa 8 GB Unbuffered non-ECC SO-DIMM, DDR3-1866MHz, in 1 DIMM slot
Tính năng
- BIOS
- AMI UEFI
Kết nối
- LAN
- 2 x RJ45 Gigabit Ethernet LAN ports
- USB
- 2 x USB 3.0 ports (2 rear)
- Kết nối khác
-
- 1 x HDMI port, 1 48-bit LVDS port,
Dual channel 48-bit LVDS(max. resolution up to 1920x1200@60Hz), HDMI(max. resolution up to 3840x2160@30Hz)
- 32 pin Connector A (2x16-Pin,2.0mm pitch):2 RS232/422/485, HD AUDIO Mic-in /Line-out (Note:Audio only support 0~60C)
- 34 pin Connector B (2x17-Pin,2.0mm pitch):Power/Reset button, HDD/Power LED, 8-bit GPIO, 2 USB2.0
- 1 x SMbus and 5V/1A SATA Power box header
- 1 x 12V DC Jack power input connector
- 1 x Half size Mini-PCI-E (USB2.0 x 1,PCI-E Gen2 x 1)
- 1 x M.2 2242/3042 B-Key (USB2.0 x 1,PCI-E Gen2 x 1,SATA Gen3 x 1)
- 1 x EI/O (1 DP/HDMI, 2 PCI-E x1, 2 USB2.0, LPC, SATA3, SMBus, 12Vsb 2A, 5Vsb 2.8A)
Thông tin chung
- Nhà sản xuất
- Supermicro
- Kích thước
- 10,16 x 7,19 cm
- Loại máy
- Bo mạch chủ
